Product Details:
|
| Condition: | New | Max. Output Power: | 1000w, 1500w, 2000w,3000w, 1000W |
|---|---|---|---|
| Usage: | Weldling | Single Pulse Energy: | 110J |
| Pulse Width: | 0.5-25ms, 0.3 - 20ms | Wavelength: | 1064nm, 1064nm |
| Focal Spot Diameter: | 0.2-3.0mm, 0.2-2 Mm | Dimensions: | 120*610*110CM |
| Warranty: | 2 Years | Laser Source Brand: | JPT |
| Laser Head Brand: | WOBBLE TYPE | Servo Motor Brand: | FUJI |
| Guiderail Brand: | TPI | Control System Brand: | Cypcut |
| Weight (KG): | 70 KG | Key Selling Points: | Hand Held Laser Welding |
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Marketing Type: | Hand Held Laser Welding |
| Warranty Of Core Components: | 2 Years | Core Components: | PLC, Laser Generator |
| Application: | Laser Welding | Cooling System: | Water Cooling System |
| Warranty Time: | 2 Year | Power Supply: | 380V/3-phase/50Hz/60A 220V/Single Phase/50Hz |
| Product Name: | Automatic Fiber Laser Welding Machine | Port: | Tianjin Port Of China |
|
Welding Capacity List
|
|
|
||
|
Laser Power
|
Laser Source / Laser Welding Head
|
Laser Melting PenetraionThickness Reference
|
||
|
1000W
Welding wire: 0.6-0.8mm |
1:CW FIBER LASER with Wobble Laser Welding Head .
2.Laser Spot Diameter Adjustable Scope: 0-4 mm 3.Welding Wires Feeding System With it . |
Steel -3 mm , Welding Speed : 15-20mm/s
Titanium Alloy-3mm ,Welding Speed :30-40mm/s Brass -2mm , Welding Speed:25-35mm/s AL-1.5mm , Welding Speed: 10-20mm/s |
||
|
|
|
|
||
|
1500W
Welding wire: 1-1.2 mm |
|
Steel -4mm , Welding Speed : 15-20mm/s
Titanium Alloy-3mm, Welding Speed: 45-55mm/s Brass -2mm, 45-50mm/s AL -2mm , 25-35mm/s |
||
|
|
|
|
||
|
2000W
Welding wire: 1.4-1.6 mm |
|
Steel –5mm ,Welding Speed:25-30mm/s
Titanium Alloy-4mm, Welding Speed :15-20mm/s Brass -2mm , Welding Speed:40-45mm/s AL -2mm , Welding Speed: 35-40mms |
||
|
|
|
|
||
|
3000W
Welding wire: 1.4-2.0 mm |
|
Steel –8mm ,Welding Speed: 30mm/s
Titanium Alloy-6mm, Welding Speed :20mm/s Brass -4mm , Welding Speed:45mm/s AL -4mm , Welding Speed: 40mms |
||
|
|
|
|
||
|
Model
|
BFW1000丨BFW 1500 丨BFW 2000 丨BFW 3000
|
|
Laser Wavelength
|
1060nm
|
|
Max laser power
|
BFW1000丨 1500W 丨 2000W 丨3000W
|
|
Welding Thickness
|
0.3-6.0mm
|
|
Welding Speed
|
0.7-2.0m/min
|
|
Fiber
|
50um,10m
|
|
Modulation frequency
|
20KHz
|
|
Energy stability
|
<3%
|
|
Cooling medium
|
Distilled water/Pure water
|
|
Continuous working time
|
24 hours
|
|
Welding method
|
pulse,continuous
|
|
Consumables
|
Protect lenses,Protect gas
|
|
Spot diameter
|
0-4mm
|
|
Power
|
4KW丨6KW 丨 8KW 丨10W
|
|
Electrical Power Source
|
220V/380V
|
|
Environment requirements
|
Clean and dust-free; temperature: 13℃-28℃,humidity: 5%-75%
|
|
LASER CLEANING SIZE
|
50MM
|
