Product Details:
|
| Application: | LASER CUTTING, Industrial Metal Cutting | Applicable Material: | Metal |
|---|---|---|---|
| Condition: | New | Laser Type: | Fiber Laser |
| Cutting Area: | 3000*1500mm | Cutting Speed: | 1-120m/min |
| Graphic Format Supported: | AI, PLT, DXF, BMP, Dst | Cutting Thickness: | 0-20mm |
| CNC Or Not: | Yes | Cooling Mode: | WATER COOLING |
| Control Software: | Cypcut | Laser Source Brand: | MAX |
| Laser Head Brand: | Raytools | Servo Motor Brand: | FUJI |
| Guiderail Brand: | HIWIN | Control System Brand: | Cypcut |
| Weight (KG): | 1700 KG | Key Selling Points: | Automatic |
| Optical Lens Brand: | Wavelength | Warranty: | 2 Years |
| Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Retail, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising Company | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 2 Years |
| Core Components: | Engine, Laser Source, Control Cabinet | Mode Of Operation: | Continuous Wave |
| Configuration: | Gantry Type | Products Handled: | Sheet Metal |
| Feature: | Automated Loading | Keyword: | Automatic Fiber Laser Cutting Machiens |
| Laser Source: | MAX IPG RAYCUS | Function: | Cutting SS CS |
| After-sales Service Provided: | Online Support | Type: | Gantry Type Fiber Lasr Cutting |
| Laser-type: | Continuous Fiber Laser | Working Area: | 1500mmX3000mm / 2000mmX4000mm / 2500mmmX6000mm |
| Cooling System: | Industrial Water Chiller | Working Voltage: | 220V/380V 50-60HZ |
|
Worktable Type :
|
Double Worktable Type
|
|
Actual Cutting Size:
|
3000x1500mm,4000x1500mm,4000x2000mm,6000x2000mm,8000x2000mm
|
|
Cutting Thickness:
|
<25mm
|
|
Materials :
|
Steel,Al, Brass,Alloy etc..
|
|
Laser Power :
|
6000W 12000W 20000W
|
|
Delivery Time :
|
45 Working Days
|
|
Warranty &Service :
|
2 Years
|
|
Model NO:
|
BFC Series
|
|
|
|
|||
|
Laser Type
|
CW FIber
|
|
|
|
|||
|
Laser Wavelength
|
1060nm
|
|
|
|
|||
|
Laser Maximum Power
|
6000W 12000W 20000W
|
|
|
|
|||
|
Max. Cutting thickness
|
≤22mm
|
|
|
|
|||
|
Total Power Consumption
|
<38KW (380v/ 3Phase/50Hz/ 110A)
|
|
|
|
|||
|
Working Size
|
3000*1500 mm/4000X2000MM/6000X2000MM/8000X2000MM
|
|
|
|
|||
|
Max.cutting speed
|
0-30m/min(Depending on the material and thickness)
|
|
|
|
|||
|
X, Y, Z Axis Orientation Precision
|
≤±0.03mm/m
|
|
|
|
|||
|
X, Y, Z Axis Repeat Precision
|
≤±0.03mm /m
|
|
|
|
|||
|
Min line width
|
≤0.15mm
|
|
|
|
|||
|
Maximum Empty Running Speed
|
120m/min
|
|
|
|
|||
|
Driving way
|
Imported servo motor
|
|
|
|
|||
|
Transmission way
|
Y-axis import gear rack double driver, X-axis imported ball screw
|
|
|
|
|||
|
Worktable Max Load
|
12Tons
|
|
|
|
|||
|
Cooling System
|
Water Cooling
|
|
|
|
|||
|
Continuous working time
|
24 Hours
|
|
|
|
|||
|
Environment temperature
|
0-35°C
|
|
|
|
|||
|
Power requirements
|
380V/3 Phases /50Hz or 60Hz
|
|
|
|
|||
